China Luxury Decoration Container Office- Quality Integrated House
NO. | NAME | DESCRIPTION | SIZE | QTY | UNIT |
一 BASIC ITEM | 1 | set | |||
1 | Roof | color steel buckle plate | 0.5mm | 1 | set |
glasswool insulation | |||||
galvanized steel keel | |||||
white metal ceiling | 0.3mm | ||||
2 | Floor | vinyl leather flooring | 1.6mm | 1 | set |
cement fiber board | 1.8mm | ||||
PE insulation film | |||||
galvanized steel keel | |||||
3 | Column | glavanized steel column | L2580mm | 4 | pc |
4 | Drain pipe | Rain drain pipes | white pvc pipe | 4 | pc |
二INCREASE ITEM | |||||
5 | Wall panel | 75mm Glasswool sandwich panel | 16.8 | m2 | |
6 | Exterior wall decoration | Hanging board | 12 | m2 | |
7 | Pergola | Anticorrosive decoration wood | 7.35 | m | |
8 | Decking | WPC | 2.88 | m2 | |
9 | Window | Aluminium-alloy window | 8.14 | m2 | |
10 | Door | white steel door | 800mm*2000mm | 1 | set |
11 | Electric system | change into local standard | 1 | set | |
Led light | 3 | pc | |||
switch | 3 | pc | |||
socket | 3 | pc | |||
12 | Water system | inlet & outlet water pipes | 0 | m2 | |
13 | Assemble Accessories | PVC cover skirting | 1 | set | |
Connection | module connection lock | 0 | set | ||
Molding covering | module top and column connection part covering | 0 | m | ||
module floor connection partcovering | 0 | m | |||
sealing tape | rubber tape filling between module connection part | 0 | m | ||
Self-glue tape | waterproof self glue tape between module connection part | 0 | m |
NORMAL QUALITY | ||
NO | ITEM | DESCRIPTION |
1 | bottom frame | beamthickness 2.5mm |
secondary purlin C120*60*1.7mm | ||
50mm glasswool insulation | ||
0.23mmcovering tile | ||
2 | top frame | beamthickness 2.5mm |
Z molding part | ||
secondary purlin 80*40*1.3mm | ||
50mm glasswool insulation+PE film | ||
0.5mm steel sheet | ||
3 | column | 2526*210*150*2.5mm |
4 | floor board | 18mm fiber cement board |
5 | floor covering | 1.6mm PVC vinyle flooring |
6 | steel door | T75 0.6mm,size 845*2035 |
7 | PVC window | pvc sliding window 1130*1100 double glasses,flying screen |
8 | wall panel | V1150,75mm glasswool sandwich panel0.4/0.450KG/m³ |
9 | Accessories | φ50mmPVC pipes |
831*0.4mm ceiling | ||
75 channel | ||
PVC skirting | ||
0.4mmcolumn cladding | ||
rivet,screw,glue,etc. | ||
10 | Electric | Industry plug,distribution box,4 socket,1switch,2 light |
11 | Lifetime | 10 years |
